v0.844a
Drive: 0(ATA)
OS: 10.0 build 22631
Model: MSI S270 240GB
Fw : SBFM61.5
Size : 228936 MB
Firmware lock supported [FB 00 01 01]
Drive unlocked [FB 00 01 03]
P/N : 511-250731165 , SBSM61.5
S11fw: SBFM61.5, 2024Mar13
S11rv: M61.5-56
Bank00: 0x98,0x3e,0xa8,0x3,0x7a,0xe4,0x8,0x1e - Toshiba 112L BiCS5 TLC 16k 512Gb/CE 512Gb/die 4Plane/die
Bank01: 0x98,0x3e,0xa8,0x3,0x7a,0xe4,0x8,0x1e - Toshiba 112L BiCS5 TLC 16k 512Gb/CE 512Gb/die 4Plane/die
Bank08: 0x98,0x3e,0xa8,0x3,0x7a,0xe4,0x8,0x1e - Toshiba 112L BiCS5 TLC 16k 512Gb/CE 512Gb/die 4Plane/die
Bank13: 0x98,0x3e,0xa8,0x3,0x7a,0xe4,0x8,0x1e - Toshiba 112L BiCS5 TLC 16k 512Gb/CE 512Gb/die 4Plane/die
Controller : PS3111
Flash CE : 4
Flash Channel : 2
Dram Size,MB : 32
Flash CE Mask : [++------ +----+--]
Flash Mode/Clk: 3/7 (Set 3/7)
Block per Die : 3324
Block per CE : 3324
Page per Block: 1344
SLC Cache : 786432(0xc0000)
PE Cycle Limit: 3000
ParPage : 00
MaxBBPerPlane : 127
Plane : 2
Defects All(per plane) Early Later
Bank00: 9(6,3) 9(6,3) 0(0,0)
Bank01: 29(21,8) 29(21,8) 0(0,0)
Bank08: 10(7,3) 10(7,3) 0(0,0)
Bank13: 51(25,26) 51(25,26) 0(0,0)
Total : 99 99 0
Early defect list
Bank00: 200 201 723 1102 2012 2356 2849 3320 3322
Bank01: 156 257 298 302 314 318 532 533 799 846 1040 1481 1718 1855 2280 2284 2419 2678 2686 2736 2795 2912 3170 3174 3186 3190 3259 3320 3322
Bank08: 99 1674 1678 1692 1694 1746 1885 2043 3320 3322
Bank13: 289 312 360 364 376 380 403 741 875 879 891 895 943 1000 1004 1027 1031 1043 1126 1245 1468 1475 1479 1481 1485 1491 1497 1501 1631 1933 2295 2307 2343 2402 2404 2406 2418 2422 2532 2580 2584 2818 2822 2825 2834 2838 2845 3164 3190 3320 3322
Later defect list
PS3111 smart configuration:
Attr Tresh Flags ValId WrstId RawId Description
0x01: 0x32 0x0B 0x0000 0x0000 0x0100 - Number of ECC Error
0x09: 0x00 0x12 0x0000 0x0000 0x0600 - Power on hours
0x0C: 0x00 0x12 0x0000 0x0000 0x0607 - Power on/off cycles
0xA8: 0x00 0x12 0x0000 0x0000 0x0103 - SATA PHY error count
0xAA: 0x00 0x03 0x0102 0x0102 0x030C - Total Early Bad Block Count/Total Later Bad Block Count
0xAD: 0x00 0x12 0x0000 0x0000 0x0204 - Max Erase Cnt/Avg Erase Cnt
0xC0: 0x00 0x12 0x0000 0x0000 0x0608 - Unexpected Power Loss Count
0xC2: 0x00 0x23 0x0300 0x0301 0x0800 - Current Temp/Min Temp/Max Temp
0xDA: 0x32 0x0B 0x0000 0x0000 0x0104 - CRC Error Count
0xE7: 0x00 0x13 0x0000 0x0000 0x020A - SSD life left
0xF1: 0x00 0x12 0x0000 0x0000 0x0402 - Host Write (GB)
