Çözüldü TP-Link VC220-G3u Root Yetkisi Elde Etme

Recep Baltaş · 24 Kasım 2025

Bildiğiniz üzere geçtiğimiz günlerde TP-Link VC220-G3u'nun config anahtarını kırdırdık. Fakat şu anda takıldığımız bir nokta var: Cihaz şifrelenmiş config dosyasını sorunsuz okuyor, kabul ediyor ve uyguladığını belirtip sistemi yeniden başlatıyor ~~ama uygulamıyor.~~ Yine başa dönmüş oluyoruz.

Burada yaptığımız bir hata var ve onu bulmaya çalışıyoruz.

Öncelikle cihazdan aldığım config dosyası:

https://www.mediafire.com/file/gkutxd99ettt6f5/conf.bin/file

Bu dosyayı aşağıdaki script ile ayıklıyoruz:

Python:

#!/usr/bin/env python3
# -*- coding: utf-8 -*-

import argparse
import sys
import re
from struct import pack, pack_into, unpack_from
from hashlib import md5
from Cryptodome.Cipher import DES

# --- GLOBAL AYARLAR ---
packint = '>I'  # VC220-G3u Big Endian kullanır
XOR_MASK = [0x74, 0x8d, 0xa5, 0x0b, 0xf9, 0x3e, 0x2d, 0xcf]

# --- YARDIMCI FONKSİYONLAR ---

def derive_key(prod_id_str):
    """Product ID stringinden (örn: '4aa13401') DES anahtarı türetir."""
    if prod_id_str.startswith("0x"):
        prod_id_str = prod_id_str[2:]

    if len(prod_id_str) != 8:
        print(f"[!] UYARI: Product ID ({prod_id_str}) 8 karakter değil! Varsayılan anahtar riskli olabilir.")
        # Yine de devam etmeye çalışalım, belki kullanıcı kısa girmiştir.
        prod_id_str = prod_id_str.ljust(8, '0')

    key_bytes = bytearray()
    for i in range(8):
        char_code = ord(prod_id_str[i])
        mask_byte = XOR_MASK[i]
        key_bytes.append(char_code ^ mask_byte)
    return bytes(key_bytes)

def extract_product_id_from_xml(xml_content):
    """XML içinden X_TP_ProductID değerini bulur."""
    # Hedef: <X_TP_ProductID ... d=0x4aa13401 ... />
    # Regex ile d=0x........ kısmını yakalayalım.
    match = re.search(rb'X_TP_ProductID.*?d=0x([0-9a-fA-F]+)', xml_content)
    if match:
        return match.group(1).decode('utf-8')
    return None

# --- SIKIŞTIRMA (ALAIN DUCHARME) ---

def compress(src):
    '''TP-Link Özel Sıkıştırma Algoritması'''
    # Son baytın NULL olduğundan emin ol
    if src and src[-1] != 0:
        src += b'\0'

    size = len(src)
    buffer_countdown = size
    hash_table = [0] * 0x2000
    dst = bytearray(0x8000)    # max buffer
    block16_countdown = 0x10
    block16_dict_bits = 0
    d_p = 7 # Header (4 byte size + 1 byte first char + 2 byte dict bits)
    d_pb = 5 # Dictionary bits position

    def put_bit(bit):
        nonlocal block16_countdown, block16_dict_bits, d_p, d_pb, dst
        if block16_countdown:
            block16_countdown -= 1
        else:
            pack_into('H', dst, d_pb, block16_dict_bits)
            d_pb = d_p
            d_p += 2
            block16_countdown = 0xF
        block16_dict_bits = (bit + (block16_dict_bits << 1)) & 0xFFFF

    def put_dict_ld(bits):
        ldb = bits >> 1
        while True:
            lb = (ldb - 1) & ldb
            if not lb: break
            ldb = lb
        put_bit(int(ldb & bits > 0))
        ldb = ldb >> 1
        while ldb:
            put_bit(1); put_bit(int(ldb & bits > 0)); ldb = ldb >> 1
        put_bit(0)

    def hash_key(offset):
        b4 = src[offset:offset+4]
        hk = 0
        for b in b4[:3]: hk = (hk + b) * 0x13d
        return ((hk + b4[3]) & 0x1FFF)

    # Header Yaz: [SIZE (4 bytes)]
    pack_into(packint, dst, 0, size)
    dst[4] = src[0] # İlk karakteri kopyala

    buffer_countdown -= 1
    s_p = 1; s_ph = 0

    while buffer_countdown > 4:
        while s_ph < s_p:
            hash_table[hash_key(s_ph)] = s_ph; s_ph += 1
        hit = hash_table[hash_key(s_p)]
        count = 0
        if hit:
            while True:
                if src[hit + count] != src[s_p + count]: break
                count += 1
                if count == buffer_countdown: break
            if count >= 4 or count == buffer_countdown:
                hit = s_p - hit - 1
                put_bit(1)
                put_dict_ld(count - 2)
                put_dict_ld((hit >> 8) + 2)
                dst[d_p] = hit & 0xFF; d_p += 1
                buffer_countdown -= count; s_p += count
                continue
        put_bit(0)
        dst[d_p] = src[s_p]; s_p += 1; d_p += 1; buffer_countdown -= 1

    while buffer_countdown:
        put_bit(0)
        dst[d_p] = src[s_p]; s_p += 1; d_p += 1; buffer_countdown -= 1

    pack_into('H', dst, d_pb, (block16_dict_bits << block16_countdown) & 0xFFFF)
    return dst[:d_p]

# --- DECOMPRESS (ŞİFRE ÇÖZMEK İÇİN) ---

def uncompress(src):
    block16_countdown = 0; block16_dict_bits = 0; s_p = 4
    def get_bit():
        nonlocal block16_countdown, block16_dict_bits, s_p
        if block16_countdown: block16_countdown -= 1
        else:
            block16_dict_bits = unpack_from('H', src, s_p)[0]; s_p += 2; block16_countdown = 0xF
        block16_dict_bits = block16_dict_bits << 1
        return 1 if block16_dict_bits & 0x10000 else 0
    def get_dict_ld():
        bits = 1
        while True:
            bits = (bits << 1) + get_bit()
            if not get_bit(): break
        return bits
    try:
        size = unpack_from(packint, src, 0)[0]
        dst = bytearray(size)
    except: return None
    s_p = 4; d_p = 0
    if s_p < len(src): dst[d_p] = src[s_p]; s_p += 1; d_p += 1
    while d_p < size:
        if get_bit():
            num_chars = get_dict_ld() + 2; msB = (get_dict_ld() - 2) << 8
            if s_p >= len(src): break
            lsB = src[s_p]; s_p += 1
            offset = d_p - (lsB + 1 + msB)
            for i in range(num_chars):
                if d_p < size: dst[d_p] = dst[offset + i]; d_p += 1
        else:
            if s_p < len(src) and d_p < size: dst[d_p] = src[s_p]; s_p += 1; d_p += 1
            else: break
    return dst

# --- ANA FONKSİYONLAR ---

def encrypt_xml(input_file, output_file):
    """XML -> BIN"""
    print(f"[*] '{input_file}' okunuyor...")
    with open(input_file, 'rb') as f:
        xml_data = f.read()

    # 1. Product ID bul ve Anahtar Üret
    pid = extract_product_id_from_xml(xml_data)
    if not pid:
        print("[!] HATA: XML içinde 'X_TP_ProductID' bulunamadı. Manuel '4aa13401' kullanılıyor.")
        pid = "4aa13401"

    key = derive_key(pid)
    print(f"[*] Product ID: {pid}")
    print(f"[*] Türetilen Anahtar: {key.hex().upper()}")

    # 2. Sıkıştır
    print("[*] Veri sıkıştırılıyor...")
    compressed_data = compress(xml_data)

    # 3. MD5 Ekle
    # Yapı: [MD5 Hash (16 byte)] + [Compressed Data (ki bunun başında size var)]
    m = md5()
    m.update(compressed_data)
    md5_header = m.digest()

    payload = md5_header + compressed_data

    # 4. Padding (DES için 8'in katı olmalı)
    pad_len = 8 - (len(payload) % 8)
    if pad_len < 8:
        payload += b'\0' * pad_len
        print(f"[*] Padding eklendi: {pad_len} byte")

    # 5. Şifrele
    print("[*] Şifreleniyor...")
    cipher = DES.new(key, DES.MODE_ECB)
    encrypted_data = cipher.encrypt(payload)

    with open(output_file, 'wb') as f:
        f.write(encrypted_data)
    print(f"🎉 BAŞARILI! Şifreli dosya: {output_file}")


def decrypt_bin(input_file, output_file):
    """BIN -> XML"""
    # Daha önce çalışan mantık, buraya entegre edildi
    with open(input_file, 'rb') as f:
        data = f.read()

    # Bu kısım biraz manuel, çünkü Product ID şifreli dosyanın içinde.
    # Kullanıcıdan Product ID isteyebiliriz veya bilinen '4aa13401' kullanırız.
    # Senin durumunda 4aa13401 sabit gibi.
    pid = "4aa13401"
    key = derive_key(pid)

    print(f"[*] Şifre çözülüyor (PID: {pid}, Key: {key.hex().upper()})...")
    cipher = DES.new(key, DES.MODE_ECB)
    try:
        decrypted = cipher.decrypt(data)
    except Exception as e:
        print(f"[!] DES Hatası: {e}")
        return

    # Header Kontrol
    payload = decrypted[16:] # MD5'i atla

    global packint
    packint = '>I' # Big Endian

    print("[*] Decompress ediliyor...")
    xml_data = uncompress(payload)

    if xml_data and b'<?xml' in xml_data:
        # Sonda kalan paddingleri temizle
        while xml_data[-1] == 0:
            xml_data = xml_data[:-1]

        with open(output_file, 'wb') as f:
            f.write(xml_data)
        print(f"🎉 BAŞARILI! XML dosya: {output_file}")
    else:
        print("[!] HATA: Decompress başarısız veya XML geçerli değil.")

if __name__ == "__main__":
    parser = argparse.ArgumentParser(description="TP-Link VC220-G3u Config Tool")
    parser.add_argument("infile", help="Giriş dosyası (conf.bin veya conf.xml)")
    parser.add_argument("-d", "--decrypt", action="store_true", help="Şifre Çöz (BIN -> XML)")
    parser.add_argument("-e", "--encrypt", action="store_true", help="Şifrele (XML -> BIN)")

    args = parser.parse_args()

    # Otomatik mod algılama
    mode = None
    if args.encrypt: mode = 'enc'
    elif args.decrypt: mode = 'dec'
    elif args.infile.endswith('.xml'): mode = 'enc'
    elif args.infile.endswith('.bin'): mode = 'dec'

    if mode == 'enc':
        outfile = args.infile.replace('.xml', '.bin')
        if outfile == args.infile: outfile += ".bin"
        encrypt_xml(args.infile, outfile)
    elif mode == 'dec':
        outfile = args.infile.replace('.bin', '.xml')
        if outfile == args.infile: outfile += ".xml"
        decrypt_bin(args.infile, outfile)
    else:
        print("[!] Mod belirlenemedi. Lütfen -e veya -d kullanın.")

Çıkan XML dosyasının sonunda uyumsuz bir karakter var:

https://www.mediafire.com/file/6ev7hqp2oba2798/conf.xml/file

Değişiklikleri yapıp root hesabını açıyoruz ama işe yaramıyor. İlk amacımız, XML'de bir değişiklik yapıp Router gerçekten bunu okuyor mu buna bakmak olacak.

@Majdev @SetoKaiba

Güncelleme: Cihazı sıfırlamadan önce config dosyaları bozuk çıkıyordu. Sıfırlama sonrası düzeldi. Sanırım bu defa olacak.
Güncelleme 2: Custom config dosyasını yedi modem. Sıra root hesabında

Şimdi cihaz config dosyasını uyguladı. Üçüncü denemede bunu ekleyip yüklüyorum, bakalım olacak mı?

XML:

      <Users>
        <UserNumberOfEntries val=2 />
        <User instance=1 >
          <Level val=1 />
          <Username val=admin />
          <Password val=admin />
          <RemoteAccessCapable val=1 />
          <Allowed_RA_Protocols val=HTTPS />
        </User>
        <User instance=2 >
          <Enable val=0 />
          <Level val=2 />
          <Username val=root />
          <Password val=wbQn09pp@G />
        </User>
        <User nextInstance=3 />
      </Users>

Güncelleme: Olumsuz. Root hesabını sildi.

XML:

<?xml version="1.0"?>
<DslCpeConfig>
  <InternetGatewayDevice>
    <DeviceSummary val="InternetGatewayDevice:1.1[](Baseline:1, EthernetLAN:1)" />
    <LANDeviceNumberOfEntries val=1 />
    <WANDeviceNumberOfEntries val=3 />
    <DeviceInfo>
      <ManufacturerOUI val=984827 />
      <SerialNumber val=5CA6E60DF4FE />
      <HardwareVersion val="VC220-G3u v2 00000001" />
      <SoftwareVersion val=VC220-G3u-v2.0_241120 />
      <UpTime val=26 />
      <X_TP_DevName val=VC220-G3u />
      <X_TTNET_SerialNumber val=5CA6E60DF4FE />
      <X_TTNET_MACAddress val=5C:A6:E6:0D:F4:FE />
      <X_TTNET_ConfigVersion val=3 />
    </DeviceInfo>
    <ManagementServer>
      <URL val=http://hdmacs-tr069.ttnet.com.tr/cwmpWeb/CPEMgt />
      <Username val=9848275CA6E60DF4FE />
      <Password val=1762039826691a />
      <PeriodicInformInterval val=99001 />
      <PeriodicInformTime val=2025-11-09T15:46:24 />
      <ParameterKey val=5241795360 />
      <X_TP_connReqPath val=/4284 />
      <ConnectionRequestURL val=http://10.183.104.92:7547/4284 />
      <ConnectionRequestUsername val=5CA6E60DF4FE-VC220-G3u-984827 />
      <ConnectionRequestPassword val=799bdf07ef897507c4cf159209c37ea5 />
      <X_TP_Flag val=1 />
      <X_TP_BoundIfName val=nas10_2 />
      <X_TTNET_ACS_IP_ETH val=127.0.0.1 />
      <Manual_uint32 val=2147483649 />
    </ManagementServer>
    <X_TP_EthSwitch>
      <EnableVirtualPorts val=1 />
      <NumberOfVirtualPorts val=4 />
      <IfName val=eth0 />
    </X_TP_EthSwitch>
    <X_TP_NetCfg>
      <DNSServers val=193.192.98.8,212.154.100.18 />
      <DNSifAliasName val=EWAN_INTERNET />
    </X_TP_NetCfg>
    <X_TP_Net6Cfg>
      <DNSv6Servers val=::,:: />
      <CurrDNSv6Server val=:: />
      <DNS6ifAliasName val=DSL_INTERNET />
    </X_TP_Net6Cfg>
    <X_TP_UserCfg>
      <AdminPwd val=wbQn09pp@G />
      <UserPwd val=admin />
      <DefaultAdminPwd val=wbQn09pp@G />
      <CurrentLanguage val=en />
    </X_TP_UserCfg>
    <X_TP_AppCfg>
      <HttpCfg>
        <HttpsRemot
jeeEnabled val=1 />
      </HttpCfg>
      <DynDnsCfg>
        <Server val=members.dyndns.org />
      </DynDnsCfg>
      <UPnPCfg>
        <Enable val=1 />
      </UPnPCfg>
      <SnmpCfg>
        <Enable val=1 />
        <SysName val=,VC220-G3u />
        <SysDescr val=VC220-G3u-v2.0_241120 />
      </SnmpCfg>
      <NoipDnsCfg>
        <State val=3 />
        <Server val=dynupdate.no-ip.com />
      </NoipDnsCfg>
      <ACL instance=1 >
        <Enable val=1 />
        <IPStart val=0.0.0.0 />
        <IPEnd val=0.0.0.0 />
        <Service val=Ping />
      </ACL>
      <ACL nextInstance=2 />
    </X_TP_AppCfg>
    <Time>
      <NTPServer1 val=0.tr.pool.ntp.org />
      <NTPServer2 val=1.tr.pool.ntp.org />
      <NTPServer3 val=2.tr.pool.ntp.org />
      <NTPServer4 val=3.tr.pool.ntp.org />
      <CurrentLocalTime val=2025-11-09T18:46:51+03:00 />
      <LocalTimeZone val=+03:00 />
      <DaylightSavingsStart val=2014-03-30T03:00:00 />
      <DaylightSavingsEnd val=2014-10-26T04:00:00 />
      <X_TP_DaylightSavingsStartWeekCount val=5 />
      <X_TP_DaylightSavingsEndWeekCount val=5 />
      <X_TP_Ifname val=ppp1 />
      <X_TP_DslIfName val=ppp0 />
      <X_TP_EwanIfName val=ppp1 />
    </Time>
    <Layer3Forwarding>
      <__defaultGateway val=172.17.1.250 />
      <__ifName val=ppp1 />
      <__ifAliasName val=EWAN_INTERNET />
      <DefaultConnectionService val=InternetGatewayDevice.WANDevice.2.WANConnectionDevice.1.WANPPPConnection.1. />
      <ForwardNumberOfEntries val=5 />
      <Forwarding instance=1 >
        <StaticRoute val=0 />
        <Type val=Network />
        <DestIPAddress val=192.168.1.0 />
        <DestSubnetMask val=255.255.255.0 />
        <SourceIPAddress val=192.168.1.1 />
        <SourceSubnetMask val=255.255.255.0 />
        <GatewayIPAddress val=0.0.0.0 />
        <Interface val=InternetGatewayDevice.LANDevice.1.LANHostConfigManagement.IPInterface.1. />
        <ForwardingMetric val=0 />
        <X_TP_SetFromUI val=0 />
        <X_TP_IfName val=br0 />
      </Forwarding>
      <Forwardi
ng instance=3 >
        <Enable val=1 />
        <Status val=Enabled />
        <StaticRoute val=0 />
        <Type val=Network />
        <DestIPAddress val=10.183.96.0 />
        <DestSubnetMask val=255.255.224.0 />
        <SourceIPAddress val=10.183.104.92 />
        <SourceSubnetMask val=255.255.224.0 />
        <GatewayIPAddress val=0.0.0.0 />
        <Interface val=InternetGatewayDevice.WANDevice.2.WANConnectionDevice.2.WANIPConnection.1. />
        <ForwardingMetric val=0 />
        <X_TP_SetFromUI val=0 />
        <X_TP_IfName val=nas10_2 />
      </Forwarding>
      <Forwarding instance=4 >
        <Enable val=1 />
        <Status val=Enabled />
        <StaticRoute val=0 />
        <Type val=Network />
        <DestIPAddress val=10.116.13.0 />
        <DestSubnetMask val=255.255.255.0 />
        <SourceIPAddress val=10.183.104.92 />
        <SourceSubnetMask val=255.255.224.0 />
        <GatewayIPAddress val=10.183.96.1 />
        <Interface val=InternetGatewayDevice.WANDevice.2.WANConnectionDevice.2.WANIPConnection.1. />
        <ForwardingMetric val=0 />
        <X_TP_SetFromUI val=0 />
        <X_TP_IfName val=nas10_2 />
      </Forwarding>
      <Forwarding instance=5 >
        <Enable val=1 />
        <Status val=Enabled />
        <StaticRoute val=0 />
        <Type val=Network />
        <DestIPAddress val=172.17.1.250 />
        <DestSubnetMask val=255.255.255.255 />
        <SourceIPAddress val=100.82.144.90 />
        <SourceSubnetMask val=255.255.255.255 />
        <GatewayIPAddress val=0.0.0.0 />
        <Interface val=InternetGatewayDevice.WANDevice.2.WANConnectionDevice.1.WANPPPConnection.1. />
        <ForwardingMetric val=0 />
        <X_TP_SetFromUI val=0 />
        <X_TP_IfName val=ppp1 />
      </Forwarding>
      <Forwarding instance=6 >
        <Enable val=1 />
        <Status val=Enabled />
        <StaticRoute val=0 />
        <Type val=Default />
        <DestIPAddress val=0.0.0.0 />
        <DestSubnetMask val=0.0.0.0 />
        <SourceIPAddress val=100.82.144.90 />
        <So
urceSubnetMask val=255.255.255.255 />
        <GatewayIPAddress val=172.17.1.250 />
        <Interface val=InternetGatewayDevice.WANDevice.2.WANConnectionDevice.1.WANPPPConnection.1. />
        <ForwardingMetric val=0 />
        <X_TP_SetFromUI val=0 />
        <X_TP_IfName val=ppp1 />
      </Forwarding>
      <Forwarding nextInstance=7 />
    </Layer3Forwarding>
    <X_TP_Layer3IPv6Forwarding>
      <__ifName val=ppp0 />
      <__ifAliasName val=DSL_INTERNET />
    </X_TP_Layer3IPv6Forwarding>
    <Layer2Bridging>
      <BridgeNumberOfEntries val=1 />
      <FilterNumberOfEntries val=16 />
      <AvailableInterfaceNumberOfEntries val=16 />
      <Bridge instance=1 >
        <BridgeEnable val=1 />
        <BridgeName val=Default />
      </Bridge>
      <Bridge nextInstance=2 />
      <Filter instance=1 >
        <FilterKey val=1 />
        <FilterEnable val=1 />
        <FilterBridgeReference val=0 />
        <__filterBridgeRefName val=Default />
        <FilterInterface val=eth0.2 />
        <X_TP_BaseLanInterfaceKey val=1 />
        <X_TP_IfAliasName val=LAN1 />
      </Filter>
      <Filter instance=2 >
        <FilterKey val=2 />
        <FilterEnable val=1 />
        <FilterBridgeReference val=0 />
        <__filterBridgeRefName val=Default />
        <FilterInterface val=eth0.3 />
        <X_TP_BaseLanInterfaceKey val=2 />
        <X_TP_IfAliasName val=LAN2 />
      </Filter>
      <Filter instance=3 >
        <FilterKey val=3 />
        <FilterEnable val=1 />
        <FilterBridgeReference val=0 />
        <__filterBridgeRefName val=Default />
        <FilterInterface val=eth0.4 />
        <X_TP_BaseLanInterfaceKey val=3 />
        <X_TP_IfAliasName val=LAN3 />
      </Filter>
      <Filter instance=4 >
        <FilterKey val=4 />
        <FilterBridgeReference val=0 />
        <__filterBridgeRefName val=Default />
        <FilterInterface val=eth0.5 />
        <X_TP_BaseLanInterfaceKey val=4 />
        <X_TP_IfAliasName val=LAN4 />
      </Filter>
      <Filter instance=5 >
        <FilterKey val=5 />
       <FilterEnable val=1 />
        <FilterBridgeReference val=0 />
        <__filterBridgeRefName val=Default />
        <FilterInterface val=ra0 />
        <X_TP_BaseLanInterfaceKey val=5 />
        <X_TP_IfAliasName val=Wi-Fi_2.4G />
      </Filter>
      <Filter instance=6 >
        <FilterKey val=6 />
        <FilterBridgeReference val=0 />
        <__filterBridgeRefName val=Default />
        <FilterInterface val=ra1 />
        <X_TP_BaseLanInterfaceKey val=6 />
        <X_TP_IfAliasName val=SSID_2.4G_01 />
      </Filter>
      <Filter instance=7 >
        <FilterKey val=7 />
        <FilterBridgeReference val=0 />
        <__filterBridgeRefName val=Default />
        <FilterInterface val=ra2 />
        <X_TP_BaseLanInterfaceKey val=7 />
        <X_TP_IfAliasName val=SSID_2.4G_02 />
      </Filter>
      <Filter instance=8 >
        <FilterKey val=8 />
        <FilterBridgeReference val=0 />
        <__filterBridgeRefName val=Default />
        <FilterInterface val=ra3 />
        <X_TP_BaseLanInterfaceKey val=8 />
        <X_TP_IfAliasName val=SSID_2.4G_03 />
      </Filter>
      <Filter instance=9 >
        <FilterKey val=9 />
        <FilterBridgeReference val=0 />
        <__filterBridgeRefName val=Default />
        <FilterInterface val=ra4 />
        <X_TP_BaseLanInterfaceKey val=9 />
        <X_TP_IfAliasName val=SSID_2.4G_R1_BH />
      </Filter>
      <Filter instance=10 >
        <FilterKey val=10 />
        <FilterBridgeReference val=0 />
        <__filterBridgeRefName val=Default />
        <FilterInterface val=ra5 />
        <X_TP_BaseLanInterfaceKey val=10 />
        <X_TP_IfAliasName val=SSID_2.4G_R2_BH />
      </Filter>
      <Filter instance=11 >
        <FilterKey val=11 />
        <FilterEnable val=1 />
        <FilterBridgeReference val=0 />
        <__filterBridgeRefName val=Default />
        <FilterInterface val=rai0 />
        <X_TP_BaseLanInterfaceKey val=11 />
        <X_TP_IfAliasName val=Wi-Fi_5G />
      </Filter>
      <Filter instance=12 >
        <FilterKey val=12 />

    <FilterBridgeReference val=0 />
        <__filterBridgeRefName val=Default />
        <FilterInterface val=rai1 />
        <X_TP_BaseLanInterfaceKey val=12 />
        <X_TP_IfAliasName val=SSID_5G_01 />
      </Filter>
      <Filter instance=13 >
        <FilterKey val=13 />
        <FilterBridgeReference val=0 />
        <__filterBridgeRefName val=Default />
        <FilterInterface val=rai2 />
        <X_TP_BaseLanInterfaceKey val=13 />
        <X_TP_IfAliasName val=SSID_5G_02 />
      </Filter>
      <Filter instance=14 >
        <FilterKey val=14 />
        <FilterBridgeReference val=0 />
        <__filterBridgeRefName val=Default />
        <FilterInterface val=rai3 />
        <X_TP_BaseLanInterfaceKey val=14 />
        <X_TP_IfAliasName val=SSID_5G_03 />
      </Filter>
      <Filter instance=15 >
        <FilterKey val=15 />
        <FilterBridgeReference val=0 />
        <__filterBridgeRefName val=Default />
        <FilterInterface val=rai4 />
        <X_TP_BaseLanInterfaceKey val=15 />
        <X_TP_IfAliasName val=SSID_5G_R1_BH />
      </Filter>
      <Filter instance=16 >
        <FilterKey val=16 />
        <FilterBridgeReference val=0 />
        <__filterBridgeRefName val=Default />
        <FilterInterface val=rai5 />
        <X_TP_BaseLanInterfaceKey val=16 />
        <X_TP_IfAliasName val=SSID_5G_R2_BH />
      </Filter>
      <Filter nextInstance=17 />
      <AvailableInterface instance=1 >
        <AvailableInterfaceKey val=1 />
        <InterfaceType val=LANInterface />
        <InterfaceReference val=LAN_ETH_INTF#1,1 />
      </AvailableInterface>
      <AvailableInterface instance=2 >
        <AvailableInterfaceKey val=2 />
        <InterfaceType val=LANInterface />
        <InterfaceReference val=LAN_ETH_INTF#1,2 />
      </AvailableInterface>
      <AvailableInterface instance=3 >
        <AvailableInterfaceKey val=3 />
        <InterfaceType val=LANInterface />
        <InterfaceReference val=LAN_ETH_INTF#1,3 />
      </AvailableInterface>
      <AvailableInterface instance=4 >

   <AvailableInterfaceKey val=4 />
        <InterfaceType val=WANInterface />
        <InterfaceReference val=LAN_ETH_INTF#1,4 />
      </AvailableInterface>
      <AvailableInterface instance=5 >
        <AvailableInterfaceKey val=5 />
        <InterfaceType val=LANInterface />
        <InterfaceReference val=LAN_WLAN#1,1 />
      </AvailableInterface>
      <AvailableInterface instance=6 >
        <AvailableInterfaceKey val=6 />
        <InterfaceType val=LANInterface />
        <InterfaceReference val=LAN_WLAN_MSSIDENTRY#1,1,1 />
      </AvailableInterface>
      <AvailableInterface instance=7 >
        <AvailableInterfaceKey val=7 />
        <InterfaceType val=LANInterface />
        <InterfaceReference val=LAN_WLAN_MSSIDENTRY#1,1,2 />
      </AvailableInterface>
      <AvailableInterface instance=8 >
        <AvailableInterfaceKey val=8 />
        <InterfaceType val=LANInterface />
        <InterfaceReference val=LAN_WLAN_MSSIDENTRY#1,1,3 />
      </AvailableInterface>
      <AvailableInterface instance=9 >
        <AvailableInterfaceKey val=9 />
        <InterfaceType val=LANInterface />
        <InterfaceReference val=LAN_WLAN_MSSIDENTRY#1,1,4 />
      </AvailableInterface>
      <AvailableInterface instance=10 >
        <AvailableInterfaceKey val=10 />
        <InterfaceType val=LANInterface />
        <InterfaceReference val=LAN_WLAN_MSSIDENTRY#1,1,5 />
      </AvailableInterface>
      <AvailableInterface instance=11 >
        <AvailableInterfaceKey val=11 />
        <InterfaceType val=LANInterface />
        <InterfaceReference val=LAN_WLAN#1,5 />
      </AvailableInterface>
      <AvailableInterface instance=12 >
        <AvailableInterfaceKey val=12 />
        <InterfaceType val=LANInterface />
        <InterfaceReference val=LAN_WLAN_MSSIDENTRY#1,5,1 />
      </AvailableInterface>
      <AvailableInterface instance=13 >
        <AvailableInterfaceKey val=13 />
        <InterfaceType val=LANInterface />
        <InterfaceReference val=LAN_WLAN_MSSIDENTRY#1,5,2 />
      </AvailableInterface>
      <Av
ailableInterface instance=14 >
        <AvailableInterfaceKey val=14 />
        <InterfaceType val=LANInterface />
        <InterfaceReference val=LAN_WLAN_MSSIDENTRY#1,5,3 />
      </AvailableInterface>
      <AvailableInterface instance=15 >
        <AvailableInterfaceKey val=15 />
        <InterfaceType val=LANInterface />
        <InterfaceReference val=LAN_WLAN_MSSIDENTRY#1,5,4 />
      </AvailableInterface>
      <AvailableInterface instance=16 >
        <AvailableInterfaceKey val=16 />
        <InterfaceType val=LANInterface />
        <InterfaceReference val=LAN_WLAN_MSSIDENTRY#1,5,5 />
      </AvailableInterface>
      <AvailableInterface nextInstance=17 />
    </Layer2Bridging>
    <LANDevice instance=1 >
      <LANEthernetInterfaceNumberOfEntries val=4 />
      <LANWLANConfigurationNumberOfEntries val=4 />
      <LANHostConfigManagement>
        <DHCPServerEnable val=1 />
        <MinAddress val=192.168.1.100 />
        <DNSServers val=192.168.1.1 />
        <IPRouters val=192.168.1.1 />
        <IPInterfaceNumberOfEntries val=1 />
        <X_TTNET_IPvX_LANMode val=1 />
        <IPInterface instance=1 >
          <Enable val=1 />
          <__ifName val=br0 />
        </IPInterface>
        <IPInterface nextInstance=2 />
      </LANHostConfigManagement>
      <X_TP_LANIPv6HostConfigManagement>
        <IPv6DNSWANConnection val=DSL_INTERNET />
        <RADVDEnable val=1 />
        <IPv6PDWANConnection val=EWAN_INTERNET />
        <PrefixDelegationWANConnection val=InternetGatewayDevice.WANDevice.2.WANConnectionDevice.1.WANPPPConnection.1. />
        <__ifName val=br0 />
        <IPv6InterfaceNumberOfEntries val=1 />
        <IPv6Interface instance=1 >
          <Enable val=1 />
          <__ifName val=br0 />
        </IPv6Interface>
        <IPv6Interface nextInstance=2 />
      </X_TP_LANIPv6HostConfigManagement>
      <LANEthernetInterfaceConfig instance=1 >
        <Enable val=1 />
        <Status val=NoLink />
        <Name val=eth0.2 />
        <__ifName val=eth0.2 />
      </LANEthernetInterfaceCo
nfig>
      <LANEthernetInterfaceConfig instance=2 >
        <Enable val=1 />
        <Status val=NoLink />
        <Name val=eth0.3 />
        <__ifName val=eth0.3 />
      </LANEthernetInterfaceConfig>
      <LANEthernetInterfaceConfig instance=3 >
        <Enable val=1 />
        <Status val=NoLink />
        <Name val=eth0.4 />
        <__ifName val=eth0.4 />
      </LANEthernetInterfaceConfig>
      <LANEthernetInterfaceConfig instance=4 >
        <Status val=Disabled />
        <Name val=eth0.5 />
        <__ifName val=eth0.5 />
      </LANEthernetInterfaceConfig>
      <LANEthernetInterfaceConfig nextInstance=17 />
      <WLANConfiguration instance=1 >
        <__apLastStatus val=1 />
        <Enable val=1 />
        <Name val=wlan0 />
        <AutoChannelEnable val=1 />
        <X_TP_PreSSID val=TP-Link_2.4GHz />
        <SSID val=Techolay />
        <BeaconType val=WPAand11i />
        <X_TP_MACAddressControlRule val=deny />
        <X_TP_Bandwidth val=Auto />
        <X_TP_OperationalBandwidth val=20M />
        <X_TP_MaxAssoc val=32 />
        <Standard val=b,g,n />
        <WPAEncryptionModes val=AESEncryption />
        <WPAAuthenticationMode val=PSKAuthentication />
        <IEEE11iEncryptionModes val=AESEncryption />
        <IEEE11iAuthenticationMode val=PSKAuthentication />
        <X_TP_PreSharedKey val=Tech0layTech0lay />
        <SSIDAdvertisementEnabled val=1 />
        <TransmitPower val=100 />
        <AutoRateFallBackEnabled val=1 />
        <DeviceOperationMode val=InfrastructureAccessPoint />
        <WMMEnable val=1 />
        <X_TP_ShortGIEnable val=1 />
        <VlanID val=4001 />
        <X_TP_APType val=Primary />
        <X_TTNET_PSS val=2 />
        <X_TP_DefaultPreSharedKey val=7w3yEVynz7yT />
        <WPS>
          <Enable val=1 />
          <DeviceName val="Turk Telekom VDSL2 Modem Router" />
          <DevicePassword val=42213895 />
          <UUID val=0x000102030405060708090a0b0c0d0ebb />
          <ConfigurationState val=Configured />
        </WPS>
        <WEPKey instance
=1 >
        </WEPKey>
        <WEPKey instance=2 >
        </WEPKey>
        <WEPKey instance=3 >
        </WEPKey>
        <WEPKey instance=4 >
        </WEPKey>
        <WEPKey nextInstance=5 />
        <PreSharedKey instance=1 >
        </PreSharedKey>
        <PreSharedKey nextInstance=2 />
        <X_TP_MultiSSID>
          <MultiSSIDEnable val=1 />
          <MultiSSIDEntry instance=1 >
            <Name val=wlan1 />
            <SSID val=Misafir1_F4FE_2.4GHz />
            <SSIDAdvertisementEnable val=1 />
            <BeaconType val=WPAand11i />
            <WPAEncryptionModes val=AESEncryption />
            <WPAAuthenticationMode val=PSKAuthentication />
            <IEEE11iEncryptionModes val=AESEncryption />
            <IEEE11iAuthenticationMode val=PSKAuthentication />
            <PreSharedKey val=zVcnvkUHvpt7 />
            <RadiusServerPort val=1812 />
            <MaxStaNum val=16 />
            <X_TP_APType val=Guest />
            <WEPKey instance=1 >
            </WEPKey>
            <WEPKey instance=2 >
            </WEPKey>
            <WEPKey instance=3 >
            </WEPKey>
            <WEPKey instance=4 >
            </WEPKey>
            <WEPKey nextInstance=5 />
          </MultiSSIDEntry>
          <MultiSSIDEntry instance=2 >
            <Name val=wlan2 />
            <SSID val=Misafir2_F4FE_2.4GHz />
            <SSIDAdvertisementEnable val=1 />
            <BeaconType val=WPAand11i />
            <WPAEncryptionModes val=AESEncryption />
            <WPAAuthenticationMode val=PSKAuthentication />
            <IEEE11iEncryptionModes val=AESEncryption />
            <IEEE11iAuthenticationMode val=PSKAuthentication />
            <PreSharedKey val=NyqwCtkFD7Na />
            <RadiusServerPort val=1812 />
            <MaxStaNum val=16 />
            <X_TP_APType val=Guest />
            <WEPKey instance=1 >
            </WEPKey>
            <WEPKey instance=2 >
            </WEPKey>
            <WEPKey instance=3 >
            </WEPKey>
            <WEPKey instance=4 >
            </
WEPKey>
            <WEPKey nextInstance=5 />
          </MultiSSIDEntry>
          <MultiSSIDEntry instance=3 >
            <Name val=wlan3 />
            <SSID val=Misafir3_F4FE_2.4GHz />
            <SSIDAdvertisementEnable val=1 />
            <BeaconType val=WPAand11i />
            <WPAEncryptionModes val=AESEncryption />
            <WPAAuthenticationMode val=PSKAuthentication />
            <IEEE11iEncryptionModes val=AESEncryption />
            <IEEE11iAuthenticationMode val=PSKAuthentication />
            <PreSharedKey val=Lpupkf9b7X4a />
            <RadiusServerPort val=1812 />
            <MaxStaNum val=16 />
            <X_TP_APType val=Guest />
            <WEPKey instance=1 >
            </WEPKey>
            <WEPKey instance=2 >
            </WEPKey>
            <WEPKey instance=3 >
            </WEPKey>
            <WEPKey instance=4 >
            </WEPKey>
            <WEPKey nextInstance=5 />
          </MultiSSIDEntry>
          <MultiSSIDEntry instance=4 >
            <Name val=wlan4 />
            <SSID val=LfMCLleK2lU2NueECKmOmzmNZOFQIL />
            <BeaconType val=11i />
            <WPAEncryptionModes val=AESEncryption />
            <WPAAuthenticationMode val=PSKAuthentication />
            <IEEE11iEncryptionModes val=AESEncryption />
            <IEEE11iAuthenticationMode val=PSKAuthentication />
            <PreSharedKey val=15NXCCJOpS9E7db2iAV9jbNcdaKuu />
            <RadiusServerPort val=1812 />
            <X_TP_APType val=Backhaul />
            <WEPKey instance=1 >
            </WEPKey>
            <WEPKey instance=2 >
            </WEPKey>
            <WEPKey instance=3 >
            </WEPKey>
            <WEPKey instance=4 >
            </WEPKey>
            <WEPKey nextInstance=5 />
          </MultiSSIDEntry>
          <MultiSSIDEntry instance=5 >
            <Name val=wlan10 />
            <SSID val=cUwksdkvPlDuRuh2BQ4nQcEFNH2uJK />
            <BeaconType val=11i />
            <WPAEncryptionModes val=AESEncryption />
            <WPAAuthenticationMode val=PSKAuthenti
cation />
            <IEEE11iEncryptionModes val=AESEncryption />
            <IEEE11iAuthenticationMode val=PSKAuthentication />
            <PreSharedKey val=yNZMfBVYqzKp0XhEAgx0Sx5wwOdAM />
            <RadiusServerPort val=1812 />
            <X_TP_APType val=Backhaul />
            <WEPKey instance=1 >
            </WEPKey>
            <WEPKey instance=2 >
            </WEPKey>
            <WEPKey instance=3 >
            </WEPKey>
            <WEPKey instance=4 >
            </WEPKey>
            <WEPKey nextInstance=5 />
          </MultiSSIDEntry>
          <MultiSSIDEntry nextInstance=6 />
        </X_TP_MultiSSID>
        <X_TP_WlBrName instance=1 >
          <IfName val=ra0 />
          <BridgeName val=br0 />
        </X_TP_WlBrName>
        <X_TP_WlBrName instance=2 >
          <IfName val=ra1 />
          <BridgeName val=br0 />
        </X_TP_WlBrName>
        <X_TP_WlBrName instance=3 >
          <IfName val=ra2 />
          <BridgeName val=br0 />
        </X_TP_WlBrName>
        <X_TP_WlBrName instance=4 >
          <IfName val=ra3 />
          <BridgeName val=br0 />
        </X_TP_WlBrName>
        <X_TP_WlBrName instance=5 >
          <IfName val=ra4 />
          <BridgeName val=br0 />
        </X_TP_WlBrName>
        <X_TP_WlBrName instance=6 >
          <IfName val=ra5 />
          <BridgeName val=br0 />
        </X_TP_WlBrName>
        <X_TP_WlBrName nextInstance=7 />
      </WLANConfiguration>
      <WLANConfiguration instance=2 >
        <Name val=wlan1 />
        <Channel val=8 />
        <AutoChannelEnable val=1 />
        <X_TP_PreSSID val=TP-Link_2.4GHz />
        <SSID val=Misafir1_F4FE_2.4GHz />
        <BeaconType val=WPAand11i />
        <X_TP_MACAddressControlRule val=deny />
        <Standard val=b,g,n />
        <BasicEncryptionModes val= />
        <WPAEncryptionModes val=AESEncryption />
        <WPAAuthenticationMode val=PSKAuthentication />
        <IEEE11iEncryptionModes val=AESEncryption />
        <IEEE11iAuthenticationMode val=PSKAuthentication />
        <X_TP_PreSharedK
ey val=zVcnvkUHvpt7 />
        <SSIDAdvertisementEnabled val=1 />
        <TransmitPower val=100 />
        <WMMEnable val=1 />
        <VlanID val=4002 />
        <X_TP_APType val=Guest />
        <X_TP_DefaultPreSharedKey val=zVcnvkUHvpt7 />
        <WPS>
          <DevicePassword val=42213895 />
        </WPS>
        <PreSharedKey instance=1 >
        </PreSharedKey>
        <PreSharedKey nextInstance=2 />
        <X_TP_MultiSSID>
        </X_TP_MultiSSID>
      </WLANConfiguration>
      <WLANConfiguration instance=3 >
        <Name val=wlan2 />
        <Channel val=8 />
        <AutoChannelEnable val=1 />
        <X_TP_PreSSID val=TP-Link_2.4GHz />
        <SSID val=Misafir2_F4FE_2.4GHz />
        <BeaconType val=WPAand11i />
        <X_TP_MACAddressControlRule val=deny />
        <Standard val=b,g,n />
        <BasicEncryptionModes val= />
        <WPAEncryptionModes val=AESEncryption />
        <WPAAuthenticationMode val=PSKAuthentication />
        <IEEE11iEncryptionModes val=AESEncryption />
        <IEEE11iAuthenticationMode val=PSKAuthentication />
        <X_TP_PreSharedKey val=NyqwCtkFD7Na />
        <SSIDAdvertisementEnabled val=1 />
        <TransmitPower val=100 />
        <WMMEnable val=1 />
        <VlanID val=4003 />
        <X_TP_APType val=Guest />
        <X_TP_DefaultPreSharedKey val=NyqwCtkFD7Na />
        <WPS>
          <DevicePassword val=42213895 />
        </WPS>
        <PreSharedKey instance=1 >
        </PreSharedKey>
        <PreSharedKey nextInstance=2 />
        <X_TP_MultiSSID>
        </X_TP_MultiSSID>
      </WLANConfiguration>
      <WLANConfiguration instance=4 >
        <Name val=wlan3 />
        <Channel val=8 />
        <AutoChannelEnable val=1 />
        <X_TP_PreSSID val=TP-Link_2.4GHz />
        <SSID val=Misafir3_F4FE_2.4GHz />
        <BeaconType val=WPAand11i />
        <X_TP_MACAddressControlRule val=deny />
        <Standard val=b,g,n />
        <BasicEncryptionModes val= />
        <WPAEncryptionModes val=AESEncryption />
        <WPAAuthenticationMode val=PSKA
uthentication />
        <IEEE11iEncryptionModes val=AESEncryption />
        <IEEE11iAuthenticationMode val=PSKAuthentication />
        <X_TP_PreSharedKey val=Lpupkf9b7X4a />
        <SSIDAdvertisementEnabled val=1 />
        <TransmitPower val=100 />
        <WMMEnable val=1 />
        <VlanID val=4004 />
        <X_TP_APType val=Guest />
        <X_TP_DefaultPreSharedKey val=Lpupkf9b7X4a />
        <WPS>
          <DevicePassword val=42213895 />
        </WPS>
        <PreSharedKey instance=1 >
        </PreSharedKey>
        <PreSharedKey nextInstance=2 />
        <X_TP_MultiSSID>
        </X_TP_MultiSSID>
      </WLANConfiguration>
      <WLANConfiguration instance=5 >
        <__apLastStatus val=2 />
        <Enable val=1 />
        <Name val=wlan5 />
        <AutoChannelEnable val=1 />
        <X_TP_PreSSID val=TP-Link_5GHz />
        <SSID val=Techolay_5GHz />
        <BeaconType val=WPAand11i />
        <X_TP_MACAddressControlRule val=deny />
        <X_TP_Band val=5GHz />
        <X_TP_Bandwidth val=Auto />
        <X_TP_OperationalBandwidth val=80M />
        <X_TP_MaxAssoc val=32 />
        <Standard val=a,n,ac />
        <WPAEncryptionModes val=AESEncryption />
        <WPAAuthenticationMode val=PSKAuthentication />
        <IEEE11iEncryptionModes val=AESEncryption />
        <IEEE11iAuthenticationMode val=PSKAuthentication />
        <X_TP_PreSharedKey val=Tech0layTech0lay />
        <SSIDAdvertisementEnabled val=1 />
        <TransmitPower val=100 />
        <AutoRateFallBackEnabled val=1 />
        <DeviceOperationMode val=InfrastructureAccessPoint />
        <WMMEnable val=1 />
        <X_TP_ShortGIEnable val=1 />
        <VlanID val=4001 />
        <X_TP_APType val=Primary />
        <X_TTNET_PSS val=2 />
        <X_TP_DefaultPreSharedKey val=7w3yEVynz7yT />
        <WPS>
          <Enable val=1 />
          <DeviceName val="Turk Telekom VDSL2 Modem Router" />
          <DevicePassword val=42213895 />
          <UUID val=0x000102030405060708090a0b0c0d0ebb />
          <ConfigurationState val=Co
nfigured />
        </WPS>
        <WEPKey instance=1 >
        </WEPKey>
        <WEPKey instance=2 >
        </WEPKey>
        <WEPKey instance=3 >
        </WEPKey>
        <WEPKey instance=4 >
        </WEPKey>
        <WEPKey nextInstance=5 />
        <PreSharedKey instance=1 >
        </PreSharedKey>
        <PreSharedKey nextInstance=2 />
        <X_TP_MultiSSID>
          <MultiSSIDEnable val=1 />
          <MultiSSIDEntry instance=1 >
            <Name val=wlan6 />
            <SSID val=Misafir1_F4FE_5GHz />
            <SSIDAdvertisementEnable val=1 />
            <BeaconType val=WPAand11i />
            <WPAEncryptionModes val=AESEncryption />
            <WPAAuthenticationMode val=PSKAuthentication />
            <IEEE11iEncryptionModes val=AESEncryption />
            <IEEE11iAuthenticationMode val=PSKAuthentication />
            <PreSharedKey val=RzhPHcUxCpT3 />
            <RadiusServerPort val=1812 />
            <MaxStaNum val=16 />
            <X_TP_APType val=Guest />
            <WEPKey instance=1 >
            </WEPKey>
            <WEPKey instance=2 >
            </WEPKey>
            <WEPKey instance=3 >
            </WEPKey>
            <WEPKey instance=4 >
            </WEPKey>
            <WEPKey nextInstance=5 />
          </MultiSSIDEntry>
          <MultiSSIDEntry instance=2 >
            <Name val=wlan7 />
            <SSID val=Misafir2_F4FE_5GHz />
            <SSIDAdvertisementEnable val=1 />
            <BeaconType val=WPAand11i />
            <WPAEncryptionModes val=AESEncryption />
            <WPAAuthenticationMode val=PSKAuthentication />
            <IEEE11iEncryptionModes val=AESEncryption />
            <IEEE11iAuthenticationMode val=PSKAuthentication />
            <PreSharedKey val=kJC7LenqgpjU />
            <RadiusServerPort val=1812 />
            <MaxStaNum val=16 />
            <X_TP_APType val=Guest />
            <WEPKey instance=1 >
            </WEPKey>
            <WEPKey instance=2 >
            </WEPKey>
            <WEPKey instance=3 >
            </WEPKey>
            <WEPKey instance=4 >
            </WEPKey>
            <WEPKey nextInstance=5 />
          </MultiSSIDEntry>
          <MultiSSIDEntry instance=3 >
            <Name val=wlan8 />
            <SSID val=Misafir3_F4FE_5GHz />
            <SSIDAdvertisementEnable val=1 />
            <BeaconType val=WPAand11i />
            <WPAEncryptionModes val=AESEncryption />
            <WPAAuthenticationMode val=PSKAuthentication />
            <IEEE11iEncryptionModes val=AESEncryption />
            <IEEE11iAuthenticationMode val=PSKAuthentication />
            <PreSharedKey val=wkDXcR4WgWxg />
            <RadiusServerPort val=1812 />
            <MaxStaNum val=16 />
            <X_TP_APType val=Guest />
            <WEPKey instance=1 >
            </WEPKey>
            <WEPKey instance=2 >
            </WEPKey>
            <WEPKey instance=3 >
            </WEPKey>
            <WEPKey instance=4 >
            </WEPKey>
            <WEPKey nextInstance=5 />
          </MultiSSIDEntry>
          <MultiSSIDEntry instance=4 >
            <Name val=wlan9 />
            <SSID val=yl3hov3sLrS2bapNoewrhWUZDK6O5K />
            <BeaconType val=11i />
            <WPAEncryptionModes val=AESEncryption />
            <WPAAuthenticationMode val=PSKAuthentication />
            <IEEE11iEncryptionModes val=AESEncryption />
            <IEEE11iAuthenticationMode val=PSKAuthentication />
            <PreSharedKey val=125whxSXbbDPFsXshAwBM6d8OFBYU />
            <RadiusServerPort val=1812 />
            <X_TP_APType val=Backhaul />
            <WEPKey instance=1 >
            </WEPKey>
            <WEPKey instance=2 >
            </WEPKey>
            <WEPKey instance=3 >
            </WEPKey>
            <WEPKey instance=4 >
            </WEPKey>
            <WEPKey nextInstance=5 />
          </MultiSSIDEntry>
          <MultiSSIDEntry instance=5 >
            <Name val=wlan11 />
            <SSID val=Zm50qgvTBEUyYAsm3OllL6Zu5N8pUZ />
            <BeaconType val=11i />
            <WPAEncryptionModes val=AESEncryption />

       <WPAAuthenticationMode val=PSKAuthentication />
            <IEEE11iEncryptionModes val=AESEncryption />
            <IEEE11iAuthenticationMode val=PSKAuthentication />
            <PreSharedKey val=ZvYsIxcwSEfyUKQq0wQBAi5h85VIz />
            <RadiusServerPort val=1812 />
            <X_TP_APType val=Backhaul />
            <WEPKey instance=1 >
            </WEPKey>
            <WEPKey instance=2 >
            </WEPKey>
            <WEPKey instance=3 >
            </WEPKey>
            <WEPKey instance=4 >
            </WEPKey>
            <WEPKey nextInstance=5 />
          </MultiSSIDEntry>
          <MultiSSIDEntry nextInstance=6 />
        </X_TP_MultiSSID>
        <X_TP_WlBrName instance=1 >
          <IfName val=rai0 />
          <BridgeName val=br0 />
        </X_TP_WlBrName>
        <X_TP_WlBrName instance=2 >
          <IfName val=rai1 />
          <BridgeName val=br0 />
        </X_TP_WlBrName>
        <X_TP_WlBrName instance=3 >
          <IfName val=rai2 />
          <BridgeName val=br0 />
        </X_TP_WlBrName>
        <X_TP_WlBrName instance=4 >
          <IfName val=rai3 />
          <BridgeName val=br0 />
        </X_TP_WlBrName>
        <X_TP_WlBrName instance=5 >
          <IfName val=rai4 />
          <BridgeName val=br0 />
        </X_TP_WlBrName>
        <X_TP_WlBrName instance=6 >
          <IfName val=rai5 />
          <BridgeName val=br0 />
        </X_TP_WlBrName>
        <X_TP_WlBrName nextInstance=7 />
      </WLANConfiguration>
      <WLANConfiguration instance=6 >
        <Name val=wlan6 />
        <Channel val=52 />
        <AutoChannelEnable val=1 />
        <X_TP_PreSSID val=TP-Link_5GHz />
        <SSID val=Misafir1_F4FE_5GHz />
        <BeaconType val=WPAand11i />
        <X_TP_MACAddressControlRule val=deny />
        <X_TP_Band val=5GHz />
        <Standard val=a,n,ac />
        <BasicEncryptionModes val= />
        <WPAEncryptionModes val=AESEncryption />
        <WPAAuthenticationMode val=PSKAuthentication />
        <IEEE11iEncryptionModes val=AESEncryption />

    <IEEE11iAuthenticationMode val=PSKAuthentication />
        <X_TP_PreSharedKey val=RzhPHcUxCpT3 />
        <SSIDAdvertisementEnabled val=1 />
        <TransmitPower val=100 />
        <WMMEnable val=1 />
        <VlanID val=4002 />
        <X_TP_APType val=Guest />
        <X_TP_DefaultPreSharedKey val=RzhPHcUxCpT3 />
        <WPS>
          <DevicePassword val=42213895 />
        </WPS>
        <PreSharedKey instance=1 >
        </PreSharedKey>
        <PreSharedKey nextInstance=2 />
        <X_TP_MultiSSID>
        </X_TP_MultiSSID>
      </WLANConfiguration>
      <WLANConfiguration instance=7 >
        <Name val=wlan7 />
        <Channel val=52 />
        <AutoChannelEnable val=1 />
        <X_TP_PreSSID val=TP-Link_5GHz />
        <SSID val=Misafir2_F4FE_5GHz />
        <BeaconType val=WPAand11i />
        <X_TP_MACAddressControlRule val=deny />
        <X_TP_Band val=5GHz />
        <Standard val=a,n,ac />
        <BasicEncryptionModes val= />
        <WPAEncryptionModes val=AESEncryption />
        <WPAAuthenticationMode val=PSKAuthentication />
        <IEEE11iEncryptionModes val=AESEncryption />
        <IEEE11iAuthenticationMode val=PSKAuthentication />
        <X_TP_PreSharedKey val=kJC7LenqgpjU />
        <SSIDAdvertisementEnabled val=1 />
        <TransmitPower val=100 />
        <WMMEnable val=1 />
        <VlanID val=4003 />
        <X_TP_APType val=Guest />
        <X_TP_DefaultPreSharedKey val=kJC7LenqgpjU />
        <WPS>
          <DevicePassword val=42213895 />
        </WPS>
        <PreSharedKey instance=1 >
        </PreSharedKey>
        <PreSharedKey nextInstance=2 />
        <X_TP_MultiSSID>
        </X_TP_MultiSSID>
      </WLANConfiguration>
      <WLANConfiguration instance=8 >
        <Name val=wlan8 />
        <Channel val=52 />
        <AutoChannelEnable val=1 />
        <X_TP_PreSSID val=TP-Link_5GHz />
        <SSID val=Misafir3_F4FE_5GHz />
        <BeaconType val=WPAand11i />
        <X_TP_MACAddressControlRule val=deny />
        <X_TP_Band val=5GHz />
        <Standard va
l=a,n,ac />
        <BasicEncryptionModes val= />
        <WPAEncryptionModes val=AESEncryption />
        <WPAAuthenticationMode val=PSKAuthentication />
        <IEEE11iEncryptionModes val=AESEncryption />
        <IEEE11iAuthenticationMode val=PSKAuthentication />
        <X_TP_PreSharedKey val=wkDXcR4WgWxg />
        <SSIDAdvertisementEnabled val=1 />
        <TransmitPower val=100 />
        <WMMEnable val=1 />
        <VlanID val=4004 />
        <X_TP_APType val=Guest />
        <X_TP_DefaultPreSharedKey val=wkDXcR4WgWxg />
        <WPS>
          <DevicePassword val=42213895 />
        </WPS>
        <PreSharedKey instance=1 >
        </PreSharedKey>
        <PreSharedKey nextInstance=2 />
        <X_TP_MultiSSID>
        </X_TP_MultiSSID>
      </WLANConfiguration>
      <WLANConfiguration nextInstance=9 />
    </LANDevice>
    <LANDevice nextInstance=2 />
    <WANDevice instance=1 >
      <WANConnectionNumberOfEntries val=2 />
      <WANCommonInterfaceConfig>
        <EnabledForInternet val=1 />
        <WANAccessType val=DSL />
      </WANCommonInterfaceConfig>
      <WANDSLInterfaceConfig>
        <Enable val=1 />
        <Status val=Up />
        <LinkEncapsulationUsed val=G.993.2_Annex_K_PTM />
        <INTLVDEPTH val=-1 />
        <ShowtimeStart val=112 />
        <X_TP_UpTime val=112 />
      </WANDSLInterfaceConfig>
      <WANConnectionDevice instance=1 >
        <WANPPPConnectionNumberOfEntries val=1 />
        <WANDSLLinkConfig>
          <Enable val=1 />
          <LinkType val=EoA />
          <DestinationAddress val=PVC:8/35 />
          <X_TP_IfName val=nas0 />
          <X_VDSL_VLANID val=35 />
        </WANDSLLinkConfig>
        <WANPTMLinkConfig>
          <X_TP_Used val=1 />
          <X_TP_VlanEnabled val=1 />
          <X_TP_VID val=35 />
          <X_TP_QosMark val=0 />
          <X_TP_MACVLANEnable val=1 />
          <X_TP_IfName val=nas8.35 />
        </WANPTMLinkConfig>
        <WANPPPConnection instance=1 >
          <Enable val=1 />
          <DefaultGateway val=0.0.0.0 />

    <Name val=DSL_INTERNET />
          <Username val= />
          <Password val= />
          <X_TP_IfName val=ppp0 />
          <X_TP_L2IfName val=nas8.35 />
          <X_TP_AtmL2IfName val=nas0_1 />
          <X_TP_PtmL2IfName val=nas8.35 />
          <X_TP_ConnectionId val=0 />
          <RemoteIPAddress val=0.0.0.0 />
          <X_TP_IPv6Enabled val=1 />
          <X_TTNET_IPv6_ExternalAddress val=:: />
          <X_TTNET_IPv6_DefaultGateway val=:: />
          <X_TTNET_IPv6_DNSServers val=::,:: />
          <X_TTNET_IPv6_PrefixDelegationEnabled val=1 />
          <X_TTNET_IPv6_SitePrefix val=:: />
          <X_TP_DefaultGateWayUsed val=1 />
          <X_TTNET_VLANID val=35 />
          <X_TTNET_IPVersion_WANMode val=1 />
          <X_TP_WANOrder val=0 />
        </WANPPPConnection>
        <WANPPPConnection nextInstance=2 />
      </WANConnectionDevice>
      <WANConnectionDevice instance=2 >
        <WANIPConnectionNumberOfEntries val=1 />
        <WANDSLLinkConfig>
          <Enable val=1 />
          <LinkType val=EoA />
          <DestinationAddress val=PVC:8/55 />
          <X_TP_IfName val=nas1 />
          <X_VDSL_VLANID val=55 />
        </WANDSLLinkConfig>
        <WANPTMLinkConfig>
          <X_TP_Used val=1 />
          <X_TP_VlanEnabled val=1 />
          <X_TP_VID val=55 />
          <X_TP_QosMark val=0 />
          <X_TP_MACVLANEnable val=1 />
          <X_TP_IfName val=nas8.55 />
        </WANPTMLinkConfig>
        <WANIPConnection instance=1 >
          <Enable val=1 />
          <Name val=DSL_IPTV />
          <X_TP_ConnectionId val=1 />
          <NATEnabled val=1 />
          <X_TP_Hostname val=VC220-G3u />
          <AddressingType val=DHCP />
          <ExternalIPAddress val=0.0.0.0 />
          <SubnetMask val=0.0.0.0 />
          <DefaultGateway val=0.0.0.0 />
          <DNSServers val=0.0.0.0,0.0.0.0 />
          <X_TP_IfName val=nas8.55 />
          <X_TP_AtmIfName val=nas1_1 />
          <X_TP_PtmIfName val=nas8.55 />
          <X_TP_IGMPProxyEnabled
val=1 />
          <X_TTNET_IPv6_AddressingType val=DHCPv6 />
          <X_TTNET_IPv6_ExternalAddress val=:: />
          <X_TTNET_IPv6_DefaultGateway val=:: />
          <X_TTNET_IPv6_DNSServers val=::,:: />
          <X_TTNET_VLANID val=55 />
          <X_TP_WANOrder val=1 />
        </WANIPConnection>
        <WANIPConnection nextInstance=2 />
      </WANConnectionDevice>
      <WANConnectionDevice nextInstance=3 />
    </WANDevice>
    <WANDevice instance=2 >
      <WANConnectionNumberOfEntries val=3 />
      <WANCommonInterfaceConfig>
        <EnabledForInternet val=1 />
        <WANAccessType val=Ethernet />
      </WANCommonInterfaceConfig>
      <WANEthernetInterfaceConfig>
        <Enable val=1 />
        <Status val=Up />
        <X_TP_IfName val=nas10 />
      </WANEthernetInterfaceConfig>
      <WANConnectionDevice instance=1 >
        <WANPPPConnectionNumberOfEntries val=1 />
        <WANEthernetLinkConfig>
          <Enable val=1 />
          <EthernetLinkStatus val=Up />
          <X_TP_VLanEnabled val=1 />
          <X_TP_VID val=35 />
          <X_TP_MACVLANEnable val=1 />
          <X_TP_IfName val=nas10_0 />
          <X_TP_QosMark val=0 />
          <X_ETH_VLANID val=35 />
        </WANEthernetLinkConfig>
        <WANPPPConnection instance=1 >
          <Enable val=1 />
          <DefaultGateway val=172.17.1.250 />
          <Name val=EWAN_INTERNET />
          <X_TP_IGMPProxyEnabled val=1 />
          <Username val= />
          <Password val= />
          <X_TP_IfName val=ppp1 />
          <X_TP_L2IfName val=nas10_0 />
          <X_TP_ConnectionId val=0 />
          <ExternalIPAddress val=100.82.144.90 />
          <RemoteIPAddress val=172.17.1.250 />
          <CurrentMRUSize val=1492 />
          <DNSServers val=193.192.98.8,212.154.100.18 />
          <X_TP_SessionID val=37940 />
          <X_TP_ServerMACAdress val=D4:C1:C8:92:06:90 />
          <X_TP_IPv6Enabled val=1 />
          <X_TTNET_IPv6_ExternalAddress val=:: />
          <X_TTNET_IPv6_DefaultGateway
 val=:: />
          <X_TTNET_IPv6_DNSServers val=::,:: />
          <X_TTNET_IPv6_PrefixDelegationEnabled val=1 />
          <X_TTNET_IPv6_SitePrefix val=:: />
          <X_TP_OriginalDNSServers val=193.192.98.8,212.154.100.18 />
          <X_TP_DefaultGateWayUsed val=1 />
          <X_TP_IPv4ReconnNumOfTimes val=1 />
          <X_TP_IPv4ReconnFlag val=1 />
          <X_TTNET_VLANID val=35 />
          <X_TTNET_IPVersion_WANMode val=1 />
          <X_TTNET_ReConnectTimes val=5 />
          <X_TP_WANOrder val=0 />
        </WANPPPConnection>
        <WANPPPConnection nextInstance=2 />
      </WANConnectionDevice>
      <WANConnectionDevice instance=2 >
        <WANIPConnectionNumberOfEntries val=1 />
        <WANEthernetLinkConfig>
          <Enable val=1 />
          <EthernetLinkStatus val=Up />
          <X_TP_MACVLANEnable val=1 />
          <X_TP_IfName val=nas10_2 />
        </WANEthernetLinkConfig>
        <WANIPConnection instance=1 >
          <Enable val=1 />
          <Name val=EWAN_MANAGEMENT />
          <X_TP_ConnectionId val=1 />
          <NATEnabled val=1 />
          <X_TP_Hostname val=,VC220-G3u />
          <AddressingType val=DHCP />
          <ExternalIPAddress val=10.183.104.92 />
          <SubnetMask val=255.255.224.0 />
          <DefaultGateway val=10.183.96.1 />
          <DNSServers val=10.98.153.234,10.98.153.226 />
          <X_TP_IfName val=nas10_2 />
          <X_TTNET_IPv6_AddressingType val=DHCPv6 />
          <X_TTNET_IPv6_ExternalAddress val=:: />
          <X_TTNET_IPv6_DefaultGateway val=:: />
          <X_TTNET_IPv6_DNSServers val=::,:: />
          <X_TP_OriginalDNSServers val=10.98.153.234,10.98.153.226 />
          <X_TP_IPv4ReconnFlag val=1 />
          <X_TTNET_Op60VendorID val="TPLINK DSLRouter dslforum.org" />
          <X_TTNET_VLANID val=0 />
          <X_TTNET_ReConnectTimes val=3 />
          <X_TP_WANOrder val=0 />
          <X_TP_BindingList>
            <FlowId val=1 />
            <ListBitmap val=32768 />
          </X_TP_BindingList>
        </WANIPConnectio
        <WANIPConnection nextInstance=2 />
      </WANConnectionDevice>
      <WANConnectionDevice instance=3 >
        <WANIPConnectionNumberOfEntries val=1 />
        <WANEthernetLinkConfig>
          <Enable val=1 />
          <EthernetLinkStatus val=Up />
          <X_TP_VLanEnabled val=1 />
          <X_TP_VID val=55 />
          <X_TP_MACVLANEnable val=1 />
          <X_TP_IfName val=nas10_1 />
          <X_TP_QosMark val=0 />
          <X_ETH_VLANID val=55 />
        </WANEthernetLinkConfig>
        <WANIPConnection instance=1 >
          <Name val=EWAN_IPTV />
          <X_TP_ConnectionId val=1 />
          <NATEnabled val=1 />
          <X_TP_Hostname val=VC220-G3u />
          <AddressingType val=DHCP />
          <ExternalIPAddress val=0.0.0.0 />
          <SubnetMask val=0.0.0.0 />
          <DefaultGateway val=0.0.0.0 />
          <DNSServers val=0.0.0.0,0.0.0.0 />
          <X_TP_IfName val=nas10_1 />
          <X_TP_IGMPProxyEnabled val=1 />
          <X_TTNET_IPv6_AddressingType val=DHCPv6 />
          <X_TTNET_IPv6_ExternalAddress val=:: />
          <X_TTNET_IPv6_DefaultGateway val=:: />
          <X_TTNET_IPv6_DNSServers val=::,:: />
          <X_TTNET_VLANID val=55 />
        </WANIPConnection>
        <WANIPConnection nextInstance=2 />
      </WANConnectionDevice>
      <WANConnectionDevice nextInstance=4 />
    </WANDevice>
    <WANDevice instance=3 >
      <WANConnectionNumberOfEntries val=1 />
      <WANCommonInterfaceConfig>
        <EnabledForInternet val=1 />
        <WANAccessType val=USB_3G />
      </WANCommonInterfaceConfig>
      <WANConnectionDevice instance=1 >
        <WANIPConnectionNumberOfEntries val=1 />
        <WANPPPConnectionNumberOfEntries val=1 />
        <X_TP_WANUSB3gLinkConfig>
          <Enable val=1 />
          <MainConnObjName val=DSL_INTERNET />
          <LocationIdx val=383 />
          <APN val=internet />
        </X_TP_WANUSB3gLinkConfig>
        <WANIPConnection instance=1 >
          <Name val=dhcp_USB_4G />
          <X_TP_ConnectionId val=0 />

     <NATEnabled val=1 />
          <AddressingType val=DHCP />
          <ExternalIPAddress val=0.0.0.0 />
          <SubnetMask val=0.0.0.0 />
          <DefaultGateway val=0.0.0.0 />
          <DNSServers val=0.0.0.0,0.0.0.0 />
          <ConnectionTrigger val=AlwaysOn />
          <X_TP_IfName val=lte0 />
          <X_TTNET_IPv6_AddressingType val=DHCPv6 />
          <X_TTNET_IPv6_ExternalAddress val=:: />
          <X_TTNET_IPv6_DefaultGateway val=:: />
          <X_TTNET_IPv6_DNSServers val=::,:: />
          <X_TP_TransportType val=DHCP4G />
          <X_TP_DefaultGateWayUsed val=1 />
        </WANIPConnection>
        <WANIPConnection nextInstance=2 />
        <WANPPPConnection instance=1 >
          <DefaultGateway val=0.0.0.0 />
          <Name val=ppp_USB_3G />
          <X_TP_IfName val=ppp3 />
          <X_TP_L2IfName val=ttyNotReady />
          <X_TP_ConnectionId val=0 />
          <RemoteIPAddress val=0.0.0.0 />
          <DNSEnabled val=1 />
          <TransportType val=PPP3G />
          <X_TTNET_IPv6_ExternalAddress val=:: />
          <X_TTNET_IPv6_DefaultGateway val=:: />
          <X_TTNET_IPv6_DNSServers val=::,:: />
          <X_TP_DefaultGateWayUsed val=1 />
        </WANPPPConnection>
        <WANPPPConnection nextInstance=2 />
      </WANConnectionDevice>
      <WANConnectionDevice nextInstance=2 />
    </WANDevice>
    <WANDevice nextInstance=4 />
    <QueueManagement>
      <X_TP_Interface instance=1 >
        <InterfaceKey val=1 />
        <InterfaceName val=WAN />
        <SchedulerAlgorithm val=2 />
        <LinkType val=0 />
        <TotalBandwidth val=512 />
        <DscpMarkEnable val=0 />
        <EthernetPriorityMarkEnable val=0 />
      </X_TP_Interface>
      <X_TP_Interface instance=2 >
        <InterfaceKey val=2 />
        <InterfaceName val=LAN />
        <SchedulerAlgorithm val=3 />
        <LinkType val=0 />
        <TotalBandwidth val=1024 />
        <DscpMarkEnable val=0 />
        <EthernetPriorityMarkEnable val=0 />
      </X_TP_Interface>
      <X_TP_Interface nex
tInstance=3 />
    </QueueManagement>
    <X_TP_ShapeControl>
      <ShapeGroupNumberOfEntries val=18 />
      <ShapeGroup instance=1 >
        <Id val=1 />
        <UpMaxBW val=1024 />
        <DownMaxBW val=1024 />
      </ShapeGroup>
      <ShapeGroup instance=2 >
        <Id val=2 />
        <UpMaxBW val=1024 />
        <DownMaxBW val=1024 />
      </ShapeGroup>
      <ShapeGroup instance=3 >
        <Id val=3 />
        <UpMaxBW val=1024 />
        <DownMaxBW val=1024 />
      </ShapeGroup>
      <ShapeGroup instance=4 >
        <Id val=4 />
        <UpMaxBW val=1024 />
        <DownMaxBW val=1024 />
      </ShapeGroup>
      <ShapeGroup instance=5 >
        <Id val=5 />
        <UpMaxBW val=1024 />
        <DownMaxBW val=1024 />
      </ShapeGroup>
      <ShapeGroup instance=6 >
        <Id val=6 />
        <UpMaxBW val=1024 />
        <DownMaxBW val=1024 />
      </ShapeGroup>
      <ShapeGroup instance=7 >
        <Id val=7 />
        <UpMaxBW val=1024 />
        <DownMaxBW val=1024 />
      </ShapeGroup>
      <ShapeGroup instance=8 >
        <Id val=8 />
        <UpMaxBW val=1024 />
        <DownMaxBW val=1024 />
      </ShapeGroup>
      <ShapeGroup instance=9 >
        <Id val=9 />
        <UpMaxBW val=1024 />
        <DownMaxBW val=1024 />
      </ShapeGroup>
      <ShapeGroup instance=10 >
        <Id val=10 />
        <UpMaxBW val=1024 />
        <DownMaxBW val=1024 />
      </ShapeGroup>
      <ShapeGroup instance=11 >
        <Id val=11 />
        <UpMaxBW val=1024 />
        <DownMaxBW val=1024 />
      </ShapeGroup>
      <ShapeGroup instance=12 >
        <Id val=12 />
        <UpMaxBW val=1024 />
        <DownMaxBW val=1024 />
      </ShapeGroup>
      <ShapeGroup instance=13 >
        <Id val=13 />
        <UpMaxBW val=1024 />
        <DownMaxBW val=1024 />
      </ShapeGroup>
      <ShapeGroup instance=14 >
        <Id val=14 />
        <UpMaxBW val=1024 />
        <DownMaxBW val=1024 />
      </ShapeGroup>
      <ShapeGroup instance=15 >
        <Id val=15 />
        <UpMaxBW val=1024 />
      <DownMaxBW val=1024 />
      </ShapeGroup>
      <ShapeGroup instance=16 >
        <Id val=16 />
        <UpMaxBW val=1024 />
        <DownMaxBW val=1024 />
      </ShapeGroup>
      <ShapeGroup instance=17 >
        <Id val=17 />
        <UpMaxBW val=1024 />
        <DownMaxBW val=1024 />
      </ShapeGroup>
      <ShapeGroup instance=18 >
        <Id val=18 />
        <UpMaxBW val=1024 />
        <DownMaxBW val=1024 />
      </ShapeGroup>
      <ShapeGroup nextInstance=19 />
    </X_TP_ShapeControl>
    <X_TP_Firewall>
      <InternalHost instance=1 >
        <RefCnt val=1 />
        <Type val=1 />
        <EntryName val=childMac1 />
        <IsParentCtrl val=1 />
      </InternalHost>
      <InternalHost instance=2 >
        <RefCnt val=1 />
        <Type val=1 />
        <EntryName val=childMac2 />
        <IsParentCtrl val=1 />
      </InternalHost>
      <InternalHost instance=3 >
        <RefCnt val=1 />
        <Type val=1 />
        <EntryName val=childMac3 />
        <IsParentCtrl val=1 />
      </InternalHost>
      <InternalHost instance=4 >
        <RefCnt val=1 />
        <Type val=1 />
        <EntryName val=childMac4 />
        <IsParentCtrl val=1 />
      </InternalHost>
      <InternalHost nextInstance=5 />
      <ExternalHost instance=1 >
        <RefCnt val=4 />
        <Type val=2 />
        <EntryName val=childUrl1 />
        <IsParentCtrl val=1 />
        <PortStart val=80 />
      </ExternalHost>
      <ExternalHost nextInstance=2 />
      <TaskSchedule instance=1 >
        <RefCnt val=4 />
        <IsParentCtrl val=1 />
        <EntryName val=childSchedule1 />
      </TaskSchedule>
      <TaskSchedule nextInstance=2 />
      <Rule instance=1 >
        <Enable val=1 />
        <RuleName val=parentCtrl1 />
        <IsParentCtrl val=1 />
        <Direction val=1 />
        <InternalHostRef val=childMac1 />
        <ExternalHostRef val=childUrl1 />
        <ScheduleRef val=childSchedule1 />
      </Rule>
      <Rule instance=2 >
        <Enable val=1 />
        <RuleName val=parentCtrl2
        <IsParentCtrl val=1 />
        <Direction val=1 />
        <InternalHostRef val=childMac2 />
        <ExternalHostRef val=childUrl1 />
        <ScheduleRef val=childSchedule1 />
      </Rule>
      <Rule instance=3 >
        <Enable val=1 />
        <RuleName val=parentCtrl3 />
        <IsParentCtrl val=1 />
        <Direction val=1 />
        <InternalHostRef val=childMac3 />
        <ExternalHostRef val=childUrl1 />
        <ScheduleRef val=childSchedule1 />
      </Rule>
      <Rule instance=4 >
        <Enable val=1 />
        <RuleName val=parentCtrl4 />
        <IsParentCtrl val=1 />
        <Direction val=1 />
        <InternalHostRef val=childMac4 />
        <ExternalHostRef val=childUrl1 />
        <ScheduleRef val=childSchedule1 />
      </Rule>
      <Rule nextInstance=5 />
      <UrlList>
        <UrlCfg instance=1 >
        </UrlCfg>
        <UrlCfg instance=2 >
        </UrlCfg>
        <UrlCfg instance=3 >
        </UrlCfg>
        <UrlCfg instance=4 >
        </UrlCfg>
        <UrlCfg instance=5 >
        </UrlCfg>
        <UrlCfg instance=6 >
        </UrlCfg>
        <UrlCfg instance=7 >
        </UrlCfg>
        <UrlCfg instance=8 >
        </UrlCfg>
        <UrlCfg instance=9 >
        </UrlCfg>
        <UrlCfg instance=10 >
        </UrlCfg>
        <UrlCfg instance=11 >
        </UrlCfg>
        <UrlCfg instance=12 >
        </UrlCfg>
        <UrlCfg instance=13 >
        </UrlCfg>
        <UrlCfg instance=14 >
        </UrlCfg>
        <UrlCfg instance=15 >
        </UrlCfg>
        <UrlCfg instance=16 >
        </UrlCfg>
        <UrlCfg instance=17 >
        </UrlCfg>
        <UrlCfg instance=18 >
        </UrlCfg>
        <UrlCfg instance=19 >
        </UrlCfg>
        <UrlCfg instance=20 >
        </UrlCfg>
        <UrlCfg instance=21 >
        </UrlCfg>
        <UrlCfg instance=22 >
        </UrlCfg>
        <UrlCfg instance=23 >
        </UrlCfg>
        <UrlCfg instance=24 >
        </UrlCfg>
        <UrlCfg instance=25 >
        </UrlCfg>
        <UrlCfg instance=26 >
     </UrlCfg>
        <UrlCfg instance=27 >
        </UrlCfg>
        <UrlCfg instance=28 >
        </UrlCfg>
        <UrlCfg instance=29 >
        </UrlCfg>
        <UrlCfg instance=30 >
        </UrlCfg>
        <UrlCfg instance=31 >
        </UrlCfg>
        <UrlCfg instance=32 >
        </UrlCfg>
        <UrlCfg instance=33 >
        </UrlCfg>
        <UrlCfg instance=34 >
        </UrlCfg>
        <UrlCfg instance=35 >
        </UrlCfg>
        <UrlCfg instance=36 >
        </UrlCfg>
        <UrlCfg instance=37 >
        </UrlCfg>
        <UrlCfg instance=38 >
        </UrlCfg>
        <UrlCfg instance=39 >
        </UrlCfg>
        <UrlCfg instance=40 >
        </UrlCfg>
        <UrlCfg instance=41 >
        </UrlCfg>
        <UrlCfg instance=42 >
        </UrlCfg>
        <UrlCfg instance=43 >
        </UrlCfg>
        <UrlCfg instance=44 >
        </UrlCfg>
        <UrlCfg instance=45 >
        </UrlCfg>
        <UrlCfg instance=46 >
        </UrlCfg>
        <UrlCfg instance=47 >
        </UrlCfg>
        <UrlCfg instance=48 >
        </UrlCfg>
        <UrlCfg instance=49 >
        </UrlCfg>
        <UrlCfg instance=50 >
        </UrlCfg>
        <UrlCfg instance=51 >
        </UrlCfg>
        <UrlCfg instance=52 >
        </UrlCfg>
        <UrlCfg instance=53 >
        </UrlCfg>
        <UrlCfg instance=54 >
        </UrlCfg>
        <UrlCfg instance=55 >
        </UrlCfg>
        <UrlCfg instance=56 >
        </UrlCfg>
        <UrlCfg instance=57 >
        </UrlCfg>
        <UrlCfg instance=58 >
        </UrlCfg>
        <UrlCfg instance=59 >
        </UrlCfg>
        <UrlCfg instance=60 >
        </UrlCfg>
        <UrlCfg instance=61 >
        </UrlCfg>
        <UrlCfg instance=62 >
        </UrlCfg>
        <UrlCfg instance=63 >
        </UrlCfg>
        <UrlCfg instance=64 >
        </UrlCfg>
        <UrlCfg instance=65 >
        </UrlCfg>
        <UrlCfg instance=66 >
        </UrlCfg>
        <UrlCfg instance=67 >
        </UrlCfg>
        <UrlCfg instance=68 >
        </UrlCfg>
        <UrlCfg i
nstance=69 >
        </UrlCfg>
        <UrlCfg instance=70 >
        </UrlCfg>
        <UrlCfg instance=71 >
        </UrlCfg>
        <UrlCfg instance=72 >
        </UrlCfg>
        <UrlCfg instance=73 >
        </UrlCfg>
        <UrlCfg instance=74 >
        </UrlCfg>
        <UrlCfg instance=75 >
        </UrlCfg>
        <UrlCfg instance=76 >
        </UrlCfg>
        <UrlCfg instance=77 >
        </UrlCfg>
        <UrlCfg instance=78 >
        </UrlCfg>
        <UrlCfg instance=79 >
        </UrlCfg>
        <UrlCfg instance=80 >
        </UrlCfg>
        <UrlCfg instance=81 >
        </UrlCfg>
        <UrlCfg instance=82 >
        </UrlCfg>
        <UrlCfg instance=83 >
        </UrlCfg>
        <UrlCfg instance=84 >
        </UrlCfg>
        <UrlCfg instance=85 >
        </UrlCfg>
        <UrlCfg instance=86 >
        </UrlCfg>
        <UrlCfg instance=87 >
        </UrlCfg>
        <UrlCfg instance=88 >
        </UrlCfg>
        <UrlCfg instance=89 >
        </UrlCfg>
        <UrlCfg instance=90 >
        </UrlCfg>
        <UrlCfg instance=91 >
        </UrlCfg>
        <UrlCfg instance=92 >
        </UrlCfg>
        <UrlCfg instance=93 >
        </UrlCfg>
        <UrlCfg instance=94 >
        </UrlCfg>
        <UrlCfg instance=95 >
        </UrlCfg>
        <UrlCfg instance=96 >
        </UrlCfg>
        <UrlCfg instance=97 >
        </UrlCfg>
        <UrlCfg instance=98 >
        </UrlCfg>
        <UrlCfg instance=99 >
        </UrlCfg>
        <UrlCfg instance=100 >
        </UrlCfg>
        <UrlCfg instance=101 >
        </UrlCfg>
        <UrlCfg instance=102 >
        </UrlCfg>
        <UrlCfg instance=103 >
        </UrlCfg>
        <UrlCfg instance=104 >
        </UrlCfg>
        <UrlCfg instance=105 >
        </UrlCfg>
        <UrlCfg instance=106 >
        </UrlCfg>
        <UrlCfg instance=107 >
        </UrlCfg>
        <UrlCfg instance=108 >
        </UrlCfg>
        <UrlCfg instance=109 >
        </UrlCfg>
        <UrlCfg instance=110 >
        </UrlCfg>
        <UrlCfg instance=111 >

 </UrlCfg>
        <UrlCfg instance=112 >
        </UrlCfg>
        <UrlCfg instance=113 >
        </UrlCfg>
        <UrlCfg instance=114 >
        </UrlCfg>
        <UrlCfg instance=115 >
        </UrlCfg>
        <UrlCfg instance=116 >
        </UrlCfg>
        <UrlCfg instance=117 >
        </UrlCfg>
        <UrlCfg instance=118 >
        </UrlCfg>
        <UrlCfg instance=119 >
        </UrlCfg>
        <UrlCfg instance=120 >
        </UrlCfg>
        <UrlCfg instance=121 >
        </UrlCfg>
        <UrlCfg instance=122 >
        </UrlCfg>
        <UrlCfg instance=123 >
        </UrlCfg>
        <UrlCfg instance=124 >
        </UrlCfg>
        <UrlCfg instance=125 >
        </UrlCfg>
        <UrlCfg instance=126 >
        </UrlCfg>
        <UrlCfg instance=127 >
        </UrlCfg>
        <UrlCfg instance=128 >
        </UrlCfg>
        <UrlCfg instance=129 >
        </UrlCfg>
        <UrlCfg instance=130 >
        </UrlCfg>
        <UrlCfg instance=131 >
        </UrlCfg>
        <UrlCfg instance=132 >
        </UrlCfg>
        <UrlCfg instance=133 >
        </UrlCfg>
        <UrlCfg instance=134 >
        </UrlCfg>
        <UrlCfg instance=135 >
        </UrlCfg>
        <UrlCfg instance=136 >
        </UrlCfg>
        <UrlCfg instance=137 >
        </UrlCfg>
        <UrlCfg instance=138 >
        </UrlCfg>
        <UrlCfg instance=139 >
        </UrlCfg>
        <UrlCfg instance=140 >
        </UrlCfg>
        <UrlCfg instance=141 >
        </UrlCfg>
        <UrlCfg instance=142 >
        </UrlCfg>
        <UrlCfg instance=143 >
        </UrlCfg>
        <UrlCfg instance=144 >
        </UrlCfg>
        <UrlCfg instance=145 >
        </UrlCfg>
        <UrlCfg instance=146 >
        </UrlCfg>
        <UrlCfg instance=147 >
        </UrlCfg>
        <UrlCfg instance=148 >
        </UrlCfg>
        <UrlCfg instance=149 >
        </UrlCfg>
        <UrlCfg instance=150 >
        </UrlCfg>
        <UrlCfg instance=151 >
        </UrlCfg>
        <UrlCfg instance=152 >
        </UrlCfg>
        <UrlCfg instance=153
        </UrlCfg>
        <UrlCfg instance=154 >
        </UrlCfg>
        <UrlCfg instance=155 >
        </UrlCfg>
        <UrlCfg instance=156 >
        </UrlCfg>
        <UrlCfg instance=157 >
        </UrlCfg>
        <UrlCfg instance=158 >
        </UrlCfg>
        <UrlCfg instance=159 >
        </UrlCfg>
        <UrlCfg instance=160 >
        </UrlCfg>
        <UrlCfg instance=161 >
        </UrlCfg>
        <UrlCfg instance=162 >
        </UrlCfg>
        <UrlCfg instance=163 >
        </UrlCfg>
        <UrlCfg instance=164 >
        </UrlCfg>
        <UrlCfg instance=165 >
        </UrlCfg>
        <UrlCfg instance=166 >
        </UrlCfg>
        <UrlCfg instance=167 >
        </UrlCfg>
        <UrlCfg instance=168 >
        </UrlCfg>
        <UrlCfg instance=169 >
        </UrlCfg>
        <UrlCfg instance=170 >
        </UrlCfg>
        <UrlCfg instance=171 >
        </UrlCfg>
        <UrlCfg instance=172 >
        </UrlCfg>
        <UrlCfg instance=173 >
        </UrlCfg>
        <UrlCfg instance=174 >
        </UrlCfg>
        <UrlCfg instance=175 >
        </UrlCfg>
        <UrlCfg instance=176 >
        </UrlCfg>
        <UrlCfg instance=177 >
        </UrlCfg>
        <UrlCfg instance=178 >
        </UrlCfg>
        <UrlCfg instance=179 >
        </UrlCfg>
        <UrlCfg instance=180 >
        </UrlCfg>
        <UrlCfg instance=181 >
        </UrlCfg>
        <UrlCfg instance=182 >
        </UrlCfg>
        <UrlCfg instance=183 >
        </UrlCfg>
        <UrlCfg instance=184 >
        </UrlCfg>
        <UrlCfg instance=185 >
        </UrlCfg>
        <UrlCfg instance=186 >
        </UrlCfg>
        <UrlCfg instance=187 >
        </UrlCfg>
        <UrlCfg instance=188 >
        </UrlCfg>
        <UrlCfg instance=189 >
        </UrlCfg>
        <UrlCfg instance=190 >
        </UrlCfg>
        <UrlCfg instance=191 >
        </UrlCfg>
        <UrlCfg instance=192 >
        </UrlCfg>
        <UrlCfg instance=193 >
        </UrlCfg>
        <UrlCfg instance=194 >
        </UrlCfg>
        <UrlCfg in
stance=195 >
        </UrlCfg>
        <UrlCfg instance=196 >
        </UrlCfg>
        <UrlCfg instance=197 >
        </UrlCfg>
        <UrlCfg instance=198 >
        </UrlCfg>
        <UrlCfg instance=199 >
        </UrlCfg>
        <UrlCfg instance=200 >
        </UrlCfg>
        <UrlCfg nextInstance=201 />
      </UrlList>
    </X_TP_Firewall>
    <X_TP_IPv6Tunnel>
      <AssociatedLanIfName val=br0 />
      <DSLite>
        <Enabled val=1 />
      </DSLite>
    </X_TP_IPv6Tunnel>
    <Services>
      <StorageService instance=1 >
        <UserAccount instance=1 >
          <Enable val=1 />
          <Username val=admin />
          <Password val=admin />
          <X_TP_SupperUser val=1 />
        </UserAccount>
        <UserAccount instance=2 >
        </UserAccount>
        <UserAccount instance=3 >
        </UserAccount>
        <UserAccount instance=4 >
        </UserAccount>
        <UserAccount instance=5 >
        </UserAccount>
        <UserAccount nextInstance=6 />
        <X_TP_DLNAMediaServer>
          <ServerState val=1 />
        </X_TP_DLNAMediaServer>
        <X_TP_SMBService>
          <Anonymous val=1 />
          <SMB_FOLDER instance=1 >
            <Alias val=volume />
            <Name val=/ />
            <Enable val=1 />
          </SMB_FOLDER>
          <SMB_FOLDER nextInstance=2 />
        </X_TP_SMBService>
        <FTPServer>
          <FTP_FOLDER instance=1 >
            <Alias val=volume />
            <Name val=/ />
            <Enable val=1 />
          </FTP_FOLDER>
          <FTP_FOLDER nextInstance=2 />
        </FTPServer>
      </StorageService>
      <StorageService nextInstance=2 />
    </Services>
    <X_TP_SysMode>
      <Mode val=ETH />
      <DSLL3ForwardingName val=DSL_INTERNET />
      <DSLL3IPv6ForwardingName val=DSL_INTERNET />
      <AutoEnable val=0 />
    </X_TP_SysMode>
    <X_TP_EWAN>
      <Enable val=1 />
      <IfName val=nas10 />
    </X_TP_EWAN>
    <X_TTNET>
      <Configuration>
        <QuantWiFiAgent>
          <Enable val=1 />
          <URL val=htt
ps://acs-fileserver.turktelekom.com.tr/fileserver/QuantWiFi/TP-LINK_VC220-G3u/wifiSpeed-G3U-TT-prod-20230411 />
          <State val=RUNNING />
          <KEY val=wV86gqaW!yFtv-st_g-YL!w />
        </QuantWiFiAgent>
        <NTP>
          <Interface val=InternetGatewayDevice.WANDevice.2.WANConnectionDevice.1.WANPPPConnection.1. />
        </NTP>
        <Icmp>
          <Enable val=3 />
          <RemoteEnable val=1 />
        </Icmp>
        <IGMPv3>
          <Enable val=0 />
        </IGMPv3>
        <ReservedMAC>
          <Enable val=0 />
        </ReservedMAC>
        <BandSteering>
          <Status val=Disabled />
        </BandSteering>
      </Configuration>
      <Users>
        <UserNumberOfEntries val=2 />
        <User instance=1 >
          <Level val=1 />
          <Username val=admin />
          <Password val=admin />
          <RemoteAccessCapable val=1 />
          <Allowed_RA_Protocols val=HTTPS />
        </User>
        <User instance=2 >
          <Enable val=0 />
          <Level val=2 />
          <Username val=root />
          <Password val=wbQn09pp@G />
        </User>
        <User nextInstance=3 />
      </Users>
      <UserInterface>
        <X_TP_LocalDomainName val=modem.local />
        <RemoteAccess>
          <Enable val=1 />
          <Protocol val=HTTPS, />
        </RemoteAccess>
        <LocalAccess>
          <Protocol val=HTTP,HTTPS, />
        </LocalAccess>
      </UserInterface>
      <PacketCapture>
        <FileName val=5CA6E60DF4FE.pcap />
        <X_TP_History instance=1 >
        </X_TP_History>
        <X_TP_History instance=2 >
        </X_TP_History>
        <X_TP_History instance=3 >
        </X_TP_History>
        <X_TP_History instance=4 >
        </X_TP_History>
        <X_TP_History instance=5 >
        </X_TP_History>
        <X_TP_History instance=6 >
        </X_TP_History>
        <X_TP_History instance=7 >
        </X_TP_History>
        <X_TP_History instance=8 >
        </X_TP_History>
        <X_TP_History instance=9 >
        </X_TP_Histor
        <X_TP_History instance=10 >
        </X_TP_History>
        <X_TP_History nextInstance=11 />
      </PacketCapture>
      <PortMirroring>
        <X_TP_History instance=1 >
        </X_TP_History>
        <X_TP_History instance=2 >
        </X_TP_History>
        <X_TP_History instance=3 >
        </X_TP_History>
        <X_TP_History instance=4 >
        </X_TP_History>
        <X_TP_History instance=5 >
        </X_TP_History>
        <X_TP_History instance=6 >
        </X_TP_History>
        <X_TP_History instance=7 >
        </X_TP_History>
        <X_TP_History instance=8 >
        </X_TP_History>
        <X_TP_History instance=9 >
        </X_TP_History>
        <X_TP_History instance=10 >
        </X_TP_History>
        <X_TP_History nextInstance=11 />
      </PortMirroring>
    </X_TTNET>
  </InternetGatewayDevice>
</DslCpeConfig>

hakan58 · 2 Mayıs 2026

Modemde internet olması şart mı?

Recep Baltaş · 2 Mayıs 2026

Hayır. İnternet olmasına gerek yok.

Freemont2.0TR · 3 Mayıs 2026

Arkadaşlar 1. yöntemde bulunan telnet aktifleştirici dosya sonrasında arayüz giriş şifresi değişiyor admin admin oluyor bilginize (45 dakika bununla uğraştım siz uğraşmayın

)

Çözüldü TP-Link VC220-G3u Root Yetkisi Elde Etme

Detaylar

Recep Baltaş

Techolay

Ferdi Burak

hakan58

Çalışkan

Recep Baltaş

Techolay

Freemont2.0TR

Gelişen

Benzer konular

Yeni konular

Yeni mesajlar
